Teltonika RUT241

Anzahl	Stückpreis
Bis 49	131,00 €* 145,00 €* (9.66% gespart)
Ab 50	127,00 €* 145,00 €* (12.41% gespart)

Preise exkl. MwSt. zzgl. Versandkosten

Versandfertig in 12 Tagen, Lieferzeit 1-3 Tage

Produktnummer: RUT241000000

Produktinformationen "Teltonika RUT241"

industrieller Mobilfunk-Router

Ausgerüstet mit 4G LTE, Wi-Fi und zwei Ethernet-Anschlüssen, bietet dieser Router eine ununterbrochene Verbindung mit einem Backup durch automatisches Failover. Industrielles Design, kompakte Größe, mehrere Anschlussschnittstellen und Kompatibilität mit RMS machen dieses Gerät zu einer hervorragenden Wahl für zahlreiche IoT- und M2M-Lösungen.

Datasheet DE

MOBILE
Mobile module	4G (LTE) – Cat 4 up to 150 Mbps, 3G – Up to 42 Mbps, 2G – UP to 236.8 kbps
Status	Signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, Bytes sent/received, connected band, IMSI, ICCID
SMS	SMS status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP
USSD	Supports sending and reading Unstructured Supplementary Service Data messages
Black/White list	Operator black/white list
Multiple PDN	Possibility to use different PDNs for multiple network access and services
Band management	Band lock, Used band status display
APN	Auto APN
Bridge	Direct connection (bridge) between mobile ISP and device on LAN
Passthrough	Router assigns its mobile WAN IP address to another device on LAN
WIRELESS
Wireless mode	IEEE 802.11b/g/n/, Access Point (AP), Station (STA)
WiFi security	WPA2-Enterprise – PEAP, WPA2-PSK, WEP, WPA-EAP, WPA-PSK; AES-CCMP, TKIP, Auto Cipher modes, client separation
SSID/ESSID	SSID stealth mode and access control based on MAC address
WiFi users	Up to 50 simultaneous connections
Wireless Hotspot	Captive portal (Hotspot), internal/external Radius server, built in customizable landing page
ETHERNET
WAN	1 x WAN port 10/100 Mbps, compliance IEEE 802.3, IEEE 802.3u standards, supports auto MDI/MDIX
LAN	1 x LAN port, 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u standards, supports auto MDI/MDIX
MODBUS TCP SLAVE
ID range	Respond to one ID in range [1;255] or any
Allow Remote Access	Allow access through WAN
Custom registers	MODBUS TCP custom register block requests, which read/write to a file inside the router, and can be used to extend MODBUS TCP Slave functionality
MODBUS TCP MASTER
Supported functions	01, 02, 03, 04, 05, 06, 15, 16
Supported data formats	8 bit: INT, UINT; 16 bit: INT, UINT (MSB or LSB first); 32 bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC)
MODBUS DATA TO SERVER
Protocol	HTTP(S), MQTT, Azure MQTT
MQTT GATEWAY
MQTT Gateway	Allows sending commands and receiving data from MODBUS Master through MQTT broker
DNP3
Supported modes	TCP Master, DNP3 Outstation
SYSTEM CHARACTERISTICS
CPU	Mediatek MIPS 24Kc 580 MHz
RAM	128 MB, DDR2
FLASH storage	16 MB, SPI Flash
INPUT / OUTPUT
Input	1 x Digital Input, 0 – 6 V detected as logic low, 8 – 30 V detected as logic high
Output	1 x Digital Output, Open collector output, max output 30 V, 300 mA
Events	Email, RMS, SMS
I/O juggler	Allows to set certain I/O conditions to initiate event
POWER
Connector	4-pin industrial DC power socket
Input voltage range	9 – 30 VDC, reverse polarity protection; surge protection >31 VDC 10us max
PoE (passive)	Passive PoE over spare pairs. Possibility to power up through LAN port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, LAN1 Port, 9 – 50 VDC
Power consumption	< 6.5 W Max
PHYSICAL INTERFACES (PORTS, LEDS, BUTTONS; SIM)
Ethernet	2 x RJ45 ports, 10/100 Mbps
I/O’s	1 x Digital Input, 1 x Digital Output on 4-pin power connector
Status LEDs	3 x Connection type status LEDs, 5 x Connection strength LEDs, 2 x LAN status LEDs, 1 x Power LED
SIM	1 x SIM slot (Mini SIM – 2FF), 1.8 V/3 V, external SIM holder
Power	1 x 4-pin power connector
Antennas	2 x SMA for LTE, 1 x RP-SMA for WiFi antenna connectors
Reset	Reboot/User default reset/Factory reset button
PHYSICAL SPECIFICATION
Casing material	Aluminium housing, plastic panels
Dimensions (W x H x D)	83 x 25 x 74 mm
Weight	125 g
Mounting options	Bottom and sideways DIN rail mounting slots
PACKAGE CONTAINS
Router RUT241 9 W EU PSU 2x LTE antennas (swivel, SMA male) 1 x WiFi antenna (swivel, RP-SMA mal) Ethernet cable (1.5 m) SIM Adapter kit QSG (Quick Start Guide) RMS Flyer Packaging box

Ethernet Ports:	1, 2
Mobilfunkstandards:	2G, 3G, 4G
SIM Karten Slots:	1
Wifi Standards:	Dual-Band 802.11 b/g/n/ac, 2.4 GHz 802.11 b/g/n
