Teltonika TRB140 industrial rugged LTE Gateway
| Quantity | Unit price |
|---|---|
| To 50 |
€100.83*
€119.00*
(15.27% saved)
|
| To 100 |
€99.83*
€119.00*
(16.11% saved)
|
| To 200 |
€98.99*
€119.00*
(16.82% saved)
|
| To 500 |
€98.15*
€119.00*
(17.52% saved)
|
| From 501 |
€97.31*
€119.00*
(18.23% saved)
|
Available, delivery time: 1-3 days
Product information "Teltonika TRB140 industrial rugged LTE Gateway"
TRB140 is an ultra-small, lightweight, and energy-efficient IoT device with mission-critical LTE Cat 4 and Gigabit Ethernet connectivity options.
Linux environment offers a high degree of customization.
This gateway is perfect for projects and applications where a single device must be upgraded with reliable and secure internet connectivity.
MOBILE
|
|
Mobile module | 4G (LTE) – Cat 4 up to 150 Mbps, 3G – Up to 42 Mbps, 2G – Up to 236.8 kbps |
Status | 4G (LTE) – Cat 4 up to 150 Mbps, 3G – Up to 42 Mbps, 2G – Up to 236.8 kbps |
SMS | SMS status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP |
USSD | Supports sending and reading Unstructured Supplementary Service Data messages |
Black/White list | Operator black/white list (by country or separate operators) |
Multiple PDN | Possibility to use different PDNs for multiple network access and services |
Band management | Band lock, Used band status display |
APN | Auto APN |
Bridge | Direct connection (bridge) between mobile ISP and device on LAN |
Passthrough | Gateway assigns its mobile WAN IP address to another device on LAN |
NETWORK
|
|
Routing | Static routing |
Network protocols | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL) |
VoIP passthrough support | H.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets |
Connection monitoring | Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection |
Firewall | Port forward, traffic rules, custom rules |
Firewall status page | View all your Firewall statistics, rules, and rule counters |
Ports management | View device ports, enable and disable each of them, turn auto-configuration on or off, change their transmission speed, and so on |
Network topology | Visual representation of your network, showing which devices are connected to which other devices |
Hotspot | Captive portal (Hotspot), internal/external Radius server, SMS authorization, internal/external landing page, walled garden, user scripts, URL parameters, user groups, individual user or group limitations, user management, 9 default customizable themes and option to upload and download customised hotspot themes |
DHCP | Static and dynamic IP allocation, DHCP Relay |
QoS / Smart Queue Management (SQM) | Traffic priority queuing by source/destination, service, protocol or port, WMM, 802.11e |
DDNS | Supported >25 service providers, others can be configured manually |
Network backup | Mobile, VRRP, Wired options, each of which can be used as an automatic Failover |
SSHFS | Possibility to mount remote file system via SSH protocol
|
ETHERNET
|
|
Ethernet
| 1 x ETH ports, 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover |
MODBUS
|
|
Supported modes | Server, Client |
Supported connection types | TCP |
Custom registers
| MODBUS TCP custom register block requests, which read/write to a file inside the router, and can be used to extend MODBUS TCP Client functionality |
Supported data formats | 8-bit: INT, UINT; 16-bit: INT, UINT (MSB or LSB first); 32-bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC), HEX, ASCII
|
MQTT GATEWAY
|
|
MQTT Gateway
| Allows sending commands and receiving data from MODBUS Server through MQTT broker |
DNP3
|
|
Supported modes
| TCP Master, DNP3 Outstation |
SYSTEM CHARACTERISTICS
| |
CPU | ARM Cortex-A7 1.2 GHz |
RAM | 128 MB, DDR2 |
FLASH storage
| 512 MB, SPI Flash |
INPUT / OUTPUT
|
|
Input | 1 x Digital Input, 0 - 6 V detected as logic low, 8 - 30 V detected as logic high |
Output | 1 x Digital Output, Open collector output, max output 30 V, 300 mA |
Events | Email, RMS, SMS |
I/O juggler
| Allows to set certain I/O conditions to initiate event |
POWER
|
|
Connector | 4-pin industrial DC power socket |
Input voltage range | 9 – 30 VDC, reverse polarity protection; surge protection >31 VDC 10us max |
PoE (passive) | Possibility to power up through LAN1 port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9 - 30 VDC |
Power consumption
| < 5 W |
PHYSICAL INTERFACES (PORTS, LEDS, BUTTONS; SIM)
| |
Ethernet | 1 x RJ45 port, 10/100/1000 Mbps |
I/O’s | 1 x Digital Input, 1 x Digital Output on 4-pin power connector |
Status LEDs | 3 x connection type status LEDs, 5 x connection strength LEDs, 2 x LAN status LEDs, 1x Power LED |
SIM | 1 x SIM slot (Mini SIM – 2FF), 1.8 V/3 V |
Power | 1 x 4-pin power connector |
Antennas | 1 x SMA for LTE |
USB
| 1 x Virtual network interface via micro USB |
Reset | Reboot/User default reset/Factory reset button
|
PHYSICAL SPECIFICATION
| |
Casing material | Aluminium housing |
Dimensions (W x H x D) | 74.5 x 25 x 64.4 mm |
Weight | 134 g |
Mounting options
| Bottom and sideways DIN rail, Flat surface |
PACKAGE CONTAINS
|
|
| |
| Mobilfunkstandards: | 2G, 3G, 4G |
|---|
